Top Links for Automatic Hooks

Shackles and Masterlinks are fundamental elements in any rigging situation, when fastening systems are required. They’re closed-loop devices—similar to an eye—that are used to make connection points in rigging and sling assemblies. The top links that unite the evo 2 automatic hook with the crane can be customized in order to adapt themselves to any kind of situation. Our different options are all made of Alloy Steel, Grade 10, Quenched and Tempered and carry a Safety Factor of MBL = 4xWLL.

evo2 Omega Shackle

(REF.: UCO8)



evo2 Omega Shackle top links
Alloy Steel, Grade 10, Quenched and Tempered

Safety Factor: MBL = 4xWLL

Finish: Painted Blue

Certification: 2.1 / 2.2 / 3.1 / MPIb / DGUV

mm.  /  in.
a    21 / 0.82
b    10 / 0.39
c     9 / 0.35
d    34 / 1.33
e   24 / 0.94
f    72 / 2.83
g   16 / 0.62
h   58 / 2.28
i    32 / 1.25
j     8  / 0.31

evo2 Pear Shackle

(REF.: UMP8)



evo2 Pear Shackle top links
Alloy Steel, Grade 10, Quenched and Tempered

Safety Factor: MBL = 4xWLL

Finish: Painted Blue

Certification: 2.1 / 2.2 / 3.1 / MPIb

mm.  /  in.
a    88 / 3.46
b    10 / 0.39
c     9 / 0.35
d    70 / 2.75
e   40 / 1.57
f    121 / 4.76
g   69 / 2.71

evo2 Omega Shackle + Masterlink 3.15

(REFS.: UCO8 + UMS16)



evo2 Omega Shackle + Masterlink 3.2 top links
Alloy Steel, Grade 10, Quenched and Tempered

Safety Factor: MBL = 4xWLL

Finish: Painted Blue

Certification: 2.1 / 2.2 / 3.1 / MTCb

mm.  /  in.

a    16 / 0.62

b   120 / 4.72

c    70 / 2.75

evo2 Omega Shackle + Masterlink 5.4

(REFS.: UCO8 + UMS18)



evo2 Omega Shackle + Masterlink 5.4 top links
Alloy Steel, Grade 10, Quenched and Tempered

Safety Factor: MBL = 4xWLL

Finish: Painted Blue

Certification: 2.1 / 2.2 / 3.1 / MPIc

mm.  /  in.

a    18 / 0.70

b   135 / 5.31

c    75 / 2.95
